HE300-4200-T
HE300-4200-T is a single-phase off-grid inverter rated at 3 kW, for solar generation and battery-connected power systems.
Power3 kW
ProtectionIP21
KNOW YOUR SYSTEM
Product overview
Its 1 MPPT tracker configuration and the PV input limits below support planning of the solar strings. Match the battery voltage range and charge/discharge limits to the selected storage system.
Check the AC output, backup operating limits and communication interfaces together when designing the installation. The tables retain model-specific ratings and distinguish optional functions from standard equipment.
- No. of MPPT trackers: 1
- Cooling Method: Intelligent air cooling
- IP Ingress Protection Rating: 21
Technical specifications
Model-specific data from the supplied product records and specification sheets. Values marked for confirmation are not included in the headline ratings.
Product & applicationBattery & energyPV inputAC output & backupPerformance & protectionMechanical & environmentPacking & logistics
| Parameter | Specification |
|---|---|
| Charging Method | Two way/three way/automatic setting |
| Model | HE300-4200-T |
| Phase | Single-phase |
| Product Name | Single-phase off-grid inverter 3 kW |
| Product Type | Off-Grid Inverter |
| Working Mode | Off-grid |
| Parameter | Specification |
|---|---|
| Battery Charge/Discharge Current (A) | 100 |
| Battery Rated Voltage (V) | 24 |
| Battery Type | Lead acid/lithium batteries |
| Mains Input Voltage (V) | 90–280 ±3 (APL); 170–280 ±3 (UPS) |
| Mains Rated Input Voltage (V) | 230 |
| Mains Max Charging Current (A) | 60 |
| Parameter | Specification |
|---|---|
| Max PV Open Circuit Voltage (V) | 500 |
| Maximum PV Input Power (kW) | 3 |
| No. of MPPT trackers | 1 |
| PV Input Open Circuit Voltage Range (V) | 30–450 |
| PV Short Circuit Current (A) | 13 |
| Parameter | Specification |
|---|---|
| AC Rated Output Power (kW) | 3 |
| Nominal AC Frequency (Hz) | 50/60 |
| Nominal AC Output Current (A) | 13.63 |
| Nominal AC Voltage (V) | 240VAC ± 5% (Single Phase) |
| Output Waveform | Sine wave |
| Mains Input Frequency (Hz) | 50/60 |
| Parameter | Specification |
|---|---|
| IP Ingress Protection Rating | 21 |
| Parameter | Specification |
|---|---|
| Cooling Method | Intelligent air cooling |
| Dimensions (W*H*D) (mm) | 402*310*105 |
| Humidity (%) | 20–95 |
| Operating Temperature (℃) | -10~50 |
| Parameter | Specification |
|---|---|
| Gross Weight (kg) | 7.45 |
| Net Weight (kg) | 6.5 |
| Packaging Size (mm) | 467*390*188 |
